Flexible hose catalog

For professionals only

Sale
Protective hose conducted / Made of plastic: Corrugated polyamid protective flexible tubing - COR-PA12-V2 (GREY)
Material: Polyamide PA 12
Color: grey
Protection degree: IP68
Temp.: -50 °C to +100 °C, short term +150 °C
Flame retardant V2 (UL94), according to FMVSS302. Self-extinguishing.
Highly flexible
ROHS
Sale
Protective hose conducted / Made of plastic: Corrugated polyamid protective flexible tubing - COR-PA12-V2 (BLACK)
Material: Polyamide PA 12
Color: black (RAL 9005) UV resistant
Protection degree: IP68
Temp.: -50 °C to +100 °C, short term +150 °C
Flame retardant V2 (UL94), according to FMVSS302. Self-extinguishing.
Highly flexible
ROHS
Sale
GPH-PU - PU flexible protection conduit
Robust and liquid tight.
IP68 acc. to EN/IEC 60529
Temp.: approx. -40°C to +90°C (peak +125°C)
Colour: blue
Sale
REF 101150: SAR-LIQUIDTIGHT-EF
PVC coated, highly flexible metal protection conduit. Robust and liquid tight. Square locked metal profile.
IP68 acc. to EN/IEC 60529.
Temp.: approx. -20 °C to +70 °C (peak +80 °C)
Colour: black
Sale
Protective hose conducted / Made of plastic: Corrugated polyamid protective flexible tubing - COR-PA6-HB (GREY)
Material: Polyamide PA 6
Color: Grey
Protection degree: IP68
Temp.: -40 °C to +120 °C, short term +150 °C
Flame retardant HB (UL94)
ROHS
Sale
Protective hose conducted / Made of plastic: Corrugated polyamid protective flexible tubing - COR-PA6-HB (BLACK)
Material: Polyamide PA 6
Color: black (RAL 9005) UV resistant
Protection degree: IP68
Temp.: -40 °C to +120 °C, short term +150 °C
Flame retardant HB (UL94)
ROHS
Sale
Protective hose conducted / Made of plastic: Corrugated polyamid protective flexible tubing - COR-PA6-V0 (GREY)
Material: Polyamide PA 6
Color: grey (RAL 7037)
Protection degree: IP68
Temp.: -40 °C to +115 °C, short term +150 °C
Flame retardant V0 (UL94), according to FMVSS302. Self-extinguishing, Type B
Static radius: ± 20mm - Dynamic radius: ± 45mm
ROHS
Railway certificate for France and Germany
Sale
Protective hose conducted / Made of plastic: Corrugated polyamid protective flexible tubing - COR-PA6-V0 (BLACK)
Material: Polyamide PA 6
Color: black (RAL 9005) UV resistant
Protection degree: IP68
Temp.: -40 °C to +115 °C, short term +150 °C
Flame retardant V0 (UL94), according to FMVSS302. Self-extinguishing, Type B
ROHS
Railway certificate for France and Germany
Sale
REF 101151: SAR-LIQUIDTIGHT-EF
PVC coated, highly flexible metal protection conduit. Robust and liquid tight. Square locked metal profile.
IP68 acc. to EN/IEC 60529.
Temp.: approx. -20 °C to +70 °C (peak +80 °C)
Colour: grey RAL 7001
Sale
REF 101124: DAR-CU
Flexible EMC metal protection conduit with tinned copper wire braid. Interlocked metal profile.
IP40 acc. to EN / IEC 60529.
Temp.: up to + 150°C
Sale
REF 101104: SAR-CU
Highly flexible EMC metal protection conduit with tinned copper wire braid. Square locked metal profile.
IP40 acc. to EN / IEC 60529.
Temp.: up to + 150°C
Sale
REF 101120: DAR
Flexible metal protection conduit. Interlocked metal profile.
IP: 40 / Temp.: to ± 400°C
Standard: Ex (DIN VDE 0165) + EMC
Sale
REF 101100: SAR
Highly flexible metal protection conduit. Square locked metal profile.
IP: 40 / Temp.: to ± 400°C
Standard: Ex (DIN VDE 0165)
Sale
REF 101122: DAR-PU
PU coated, flexible metal protection conduit. Robust and liquid tight. Interlocked metal profile.
IP68 acc. to EN/IEC 60529
Temp.: approx. -40°C to +90°C (peak +125°C)
Colour: blue
Sale
REF 101102: SAR-PU
PU coated, highly flexible metal protection conduit. Robust and liquid tight. Square locked metal profile.
IP68 acc. to EN/IEC 60529
Temp.: approx. -40°C to +90°C (peak +125°C)
Colour: blue
Sale
REF 101105: SAR-AG
Highly flexible EMC metal protection conduit with galvanized steel braid. Square locked metal profile.
IP40 acc. to EN/IEC 60529.
Temp.: up to +250 °C
Sale
REF 101101: SAR-PVC
PVC coated, highly flexible metal protection conduit. Robust and liquid tight. Square locked metal profile.
IP68 acc. to EN/IEC 60529.
Temp.: approx. -20 °C to +70 °C (peak +80 °C)
Colour: grey RAL 7001
Sale
Protective hose conducted / Made of plastic: COR-DUO-PA6 UL94 V2 - REF 103151
Material: Polyamide PA6
Profile: Corrugated
Color: Black
Protection degree: IP50
Temp.: -40 °C to +115 °C, short term +150 °C
Alternative: UL94 V0 on request
