Industrial flexible hose AEROCLIMA® CLIP KAPTON C400 - 542500400
Flexible suction air hose, light and gas-tight, with internal Kapton® layer and coated glass fibre fabric. Small bending radius and highly compressible 1:4. Suitable for air exhaust systems in the extraction of corrosive media. DuPont™ Kapton® polyimide films for heat insulation.
Sale
AEROCLIMA® CLIP TEFLON C250: REF 542-35-0250
Light, very flexible suction hose in Teflon® coated glass fabric, with galvanised steel spiral. Suitable for the paint, paper, pharmaceutical and chemical industries and the extraction of corrosive media, solvents and paint mist.
Sale
AEROCLIMA® CLIP VITON C210: REF 542-30-0210
Light, very flexible suction hose in Viton® coated polyester fabric. Suitable for the paint, paper, pharmaceutical and chemical industries and the extraction of corrosive media, solvents and paint mist.
Sale
Industrial flexible hose AEROCLIMA® CLIP HYTEF C170 - 542700170
Light, very flexible suction hose, suitable for the paint, wood, paper, pharmaceutical and chemical industries and the extraction of corrosive media, solvents and paint mist. Inner ply in Teflon® film, outer ply in Hypalon® coated polyester fabric, with galvanised steel spiral.
Sale
Rubber expansion bellow with union coupling - 413FTUA
Rubber expansion joint for axial, lateral and angular movements, with union couplings
Choice between different elastomers: EPDM, NEOPRENE, NITRILE
From DN20 (3/4'') to DN80 (3'')
Sale
Rubber expansion bellow with loose flanges - 413FSFA
Rubber expansion joint for axial, lateral and angular movements, with loose flanges
Choice between different elastomers: EPDM, NEOPRENE, NITRILE, HYPALON, VITON
From DN25 (1'') to DN750 (30'')
Length: 152mm (DN25 to DN200), 203mm (DN250 to DN500), 254mm (DN550 to DN750)
Sale
AEROCLIMA® CLIP CSM C170: REF 542-25-0170
Light, very flexible suction hose with small bending radius and Hypalon® coated polyester fabric wall. Suitable for air conditioning, vantilation and heating systems, vehicle and engine construction and extraction of corrosive media.
Sale
PP RVS COMPOSITE HOSE BS / EN 13765:2010: REF 452
INDUMAT PP SS COMPOSITE BS / EN 13765 – general use chemical hose suitable for the suction and the delivery of a wide variety of acids, bases, solvents and petroleum products.
Coating and strengthening in PP
Inside and outside helix in stainless steel
Temperature: -30 °C to +80 °C
Dimensions: DN25 to DN200
Assembly option with brass or stainless steel fittings
Sale
PTFE S.F. DN10 D10 (AISI316L) x F1/2 90° (AISI316L) DI: REF 437002-C90
PTFE flexible hose reinforced with Stainless steel braid
Sale
AZUR L DN 25 (25,0 x 29,4): REF 246025
Working Pressure (WP) at 23°C: 4 Bar
Security coefficient at 20°C: 3 times the WP
Vacuum: 5
Temperature: -10°C to +60°C
Sale
AZUR DN 13 - DN 150: REF 244
Plasticized PVC hose reinforced by a rigid PVC spiral (anti shock). Smooth inner layer in transparent crystal. Easy to use, light and flexible.
Temperature range: -10 till 60°C
Applications: Suction and discharge hose for e.g. agriculture, pumps
Sale
AMAZONE SE DN 20 - DN 200: REF 212
Plasticized super elastic PVC hose reinforced by a rigid PVC spiral (anti shock). Smooth inner layer. Easy to use even at low temperatures
Temperature range: -20 till 60°C
Applications: Suction and discharge for used water, especially as equipment for trucks.
Sale
Opal PVC flexible suction hose from DN20 to DN120
Flexible hose in opaline PVC for suction and discharge
Plasticised PVC hose reinforced by a rigid PVC spiral
Temperature: -10°C to +60°C
Smooth inner layer in transparent crystal with food quality
Sale
Stainless steel expansion joint with fixed flange + inner guide tube and external protective sleeve - 412FIM
Stainless steel expansion joint with fixed flanges and inner guide tube for axial movements.
Sale
Stainless steel expansion joint with welding connection - Type SI with external protective sleeve - 412SIM
Stainless steel expansion joint for axial movements, with inner guide tube & welding connection.
Sale
Stainless steel expansion joint with fixed flanges - 412FF
Stainless steel expansion joint for axial, lateral and angular movements, with fixed flanges
Sale
Stainless steel bellow with rotating flanges - 412FB
Stainless steel expansion joint for axial, lateral and angular movements, with swivel flanges
Sale
Stainless steel bellow with female thread (fig340) - Type HV with external protective sleeve - 412HVM
Stainless steel expansion joint for axial, lateral and angular movements, often used in sanitary installations. Union coupling with flat seal and internal thread. DN15 -> DN50
Sale
Stainless steel bellow with female thread (fig340) - Type VGI with greater length - 412HV
Stainless steel expansion joint for axial, lateral and angular movements, often used in sanitary installations. Union coupling with flat seal and internal thread. DN15 -> DN50
