Flexible hose catalog

For professionals only

Categories
Stainless steel Flexible hoses - Heater / Fan coil hoses INOX-EXPAND® M3/4" x F3/4" (AISI303) - 426020IN
0.00 € 0.0 EUR
INOX-EXPAND® expandable stainless steel AISI304 flexible hose with welded fittings for air-conditioning appliances with maximum work pressure of ± 5 bar - Available in DN13 / DN20 / DN25
Stainless steel flexible hoses - Heater / Fan coil hoses INOX-EXPAND® F 3/4'' x F 3/4'' - 4260201
0.00 € 0.0 EUR
INOX-EXPAND® expandable stainless steel AISI304 flexible hose with welded fittings for air-conditioning appliances with maximum work pressure of ± 5 bar - Available in DN13 / DN20 / DN25
Stainless steel flexible hoses AISI304 - Heater / Fan coil hoses INOX-EXPAND® F 3/4" (AISI303) x F 3/4" (AISI303) - 4260201IN
0.00 € 0.0 EUR
INOX-EXPAND® expandable stainless steel AISI304 flexible hose with welded fittings for air-conditioning appliances with maximum work pressure of ± 5 bar - Available in DN13 / DN20 / DN25
Exhaust gas metal hose according to DIN 14572 - code 59113
0.00 € 0.0 EUR
Metal hose for gas exhaust of power generators, according to DIN 14572. With wooden handles for thermal insulation.
Lock-nut stainless steel - Metrical thread - 100520
0.00 € 0.0 EUR
From M75 only in stainless steel AISI303
Electric stainless steel Pipes for cables - 1006700
0.00 € 0.0 EUR
Electro-coupled stainless steel pipes.
Protection against electromagnetic interference over a wide frequency range.
EN 10088-1 = AISI 304 (X5CrNi1810) or AISI 316L (X2CrNiMo17-12-2)
Uniformly brushed stainless steel with a good surface finishing.
Cold bending, even with limited radius (3 times Ø)
Standards: EN 61386-1 (5545), EN 61386-21, EN 60423
Protection class IP66 / IP67 (EN 60529)
Compression 4000N - Shock 20J
Tensile strenght 1000N - Suspended load 450N
Corrosion resistance = 4 (high)
EMC shielding = Level 1
Electrical continuity guaranteed
Electric galvanized steel pipes for cables - 1006008
0.00 € 0.0 EUR
Electro-coupled steel pipes.
Protection against electromagnetic interference over a wide frequency range.
Cold bending, even with limited radius (3 times Ø)
Standards: EN 61386-1 (5545), EN 61386-21, EN 60423
Protection class IP66 / IP67 (EN 60529)
Compression 4000 N - Shock 20 J
Tensile strenght 1000 N - Suspended load 450 N
Corrosion resistance = 2 (medium)
Guaranteed electrical continuity
Electrical junction box in aluminium - 100653
0.00 € 0.0 EUR
Characteristics:
Junction boxes made of aluminium alloy with epoxy resin finish and AISI 304 stainless steel screws.
Temperature range: -25°C until +90°C
Properties: Electrical continuity

Standards compliance:
CEI EN 60670 + CEI 23-48
EN 60529: IP66/67
EN 50102, Rating: IK07
Alloy: EN AB 46100 in conformity with EN 1676
Metallic interlocked galvanised steel hose - 591
0.00 € 0.0 EUR

Metallic air suction and exhaust hose - interlocked galvanised steel with or without sealing.
Stainless steel Flexible hoses - Heater / Fan coil hoses - INOX-EXPAND® M1/2" x F1/2" (AISI303) - 426013IN
0.00 € 0.0 EUR
INOX-EXPAND® expandable stainless steel AISI304 flexible hose with welded fittings for air-conditioning appliances with maximum work pressure of ± 5 bar - Available in DN13 / DN20 / DN25
Stainless steel Flexible hoses - Heater / Fan coil hoses - INOX-EXPAND® M1/2xF1/2 - 426013
0.00 € 0.0 EUR
INOX-EXPAND® expandable stainless steel AISI304 flexible hose with welded fittings for air-conditioning appliances or heat pumps with maximum work pressure of ± 5 bar - Available in DN13 / DN20 / DN25
Stainless steel Flexible hoses - Heater / Fan coil hoses - INOX-EXPAND® F1/2xF1/2 - 4260131
0.00 € 0.0 EUR
INOX-EXPAND® expandable stainless steel AISI304 flexible hose with welded fittings for air-conditioning appliances with maximum work pressure of ± 5 bar - Available in DN13 / DN20 / DN25
