Flexible hose catalog

For professionals only

Sale
UNIVERSAL CABLE GLANDS for flat and round cables - Aluminium - 100139
Material: brass, nickel-plated
Sealing insert: CR
Temperature range: -20 °C to 80 °C
Protection type: IP 54

Sale
CABLE GLANDS DIN 89280 - Brass - Metric thread - 100129-W
For the marine sector

Material: Brass
Sealing ring simple: Polycloroprene
Temperature range: -20 °C to 80 °C
Protection type: IP 54
Equipment: "W" for unscreened cable

Thread M18x1.5 to M105x2 for cables from Ø7mm to Ø83mm.
Sale
CABLE GLANDS DIN 89280 - Brass - Metric thread - 100129-Z
For the marine sector

Material: Brass
Sealing ring simple: Polycloroprene
Temperature range: -20 °C to 80 °C
Protection type: IP 54
Equipment: "Z" for screened cable

Thread M18x1.5 to M105x2 for cables from Ø7mm to Ø73mm.
Sale
CABLE GLANDS DIN 89280 - Brass - PG thread - 100129-Z
For the marine sector

Material: Brass
Sealing ring simple: Polycloroprene
Temperature range: -20 °C to 80 °C
Protection type: IP 54
Equipment: "Z" for screened cable

Thread Pg 9 to Pg 48 for cables from Ø7mm to Ø56.5mm.
Sale
CABLE GLANDS DIN 89280 - Brass - PG thread - 100129-W
For the marine sector

Material: Brass
Sealing ring simple: Polycloroprene
Temperature range: -20 °C to 80 °C
Protection type: IP 54
Equipment: "W" for unscreened cable

Thread Pg 9 to Pg 48 for cables from Ø7mm to Ø56.5mm.
Sale
CABLE GLANDS - Brass - Short, PG thread - 100121
Material: brass, nickel-plated
Sealing ring simple: soft rubber
Temperature range: -20 °C to 60 °C
Protection type: IP 54

Thread Pg 7 to Pg 48 for cables from Ø4mm to Ø47mm.
Sale
CABLE GLANDS - Brass - Long, PG thread - 100121-20
Material: brass, nickel-plated
Sealing ring simple: soft rubber
Temperature range: -20 °C to 60 °C
Protection type: IP 54

Thread Pg 7 to Pg 48 for cables from Ø4mm to Ø47mm.
Sale
CABLE GLANDS - Brass - Long, metric thread - 100121-26
Material: brass, nickel-plated
Universal sealing ring: NBR / CR
Temperature range: -20 °C to 80 °C
Protection type: IP 54

Thread M16x1.5 to M63x1.5 for cables from Ø2mm to Ø51mm.
Sale
CABLE GLANDS - Brass - Short, metric thread - 100121-06
Material: brass, nickel-plated
Universal sealing ring: NBR / CR
Temperature range: -20 °C to 80 °C
Protection type: IP 54

Thread M16x1.5 to M63x1.5 for cables from Ø2mm to Ø51mm.
Sale
UNI-EV - Brass - PG thread - 100108-00
Material: brass, nickel-plated
Sealing insert: TPE
O-ring: NBR
Temperature range: -40 °C to 130 °C
Protection type: IP 68
Sale
UNI-EV - Brass - Metric thread - 100108-00
Material: brass, nickel-plated
Sealing insert: TPE
O-ring: NBR
Strain relief: acc. to EN 50262, version A
Temperature range: -40 °C to 130 °C
Protection type: IP 68
Sale
UNI-DICHT / MF - Brass - PG thread - 100106-14
Material: brass, nickel-plated
Sealing insert: PVC
O-ring: NBR
Temperature range: -20 °C to 100°C
Protection type: IP 65

Thread Pg 9 to Pg 48 for cables from Ø1.2mm to Ø18mm.
Sale
UNI-DICHT / MF - Brass - Metric thread - 100106-14
Material: brass, nickel-plated
Sealing insert: TPE
O-ring: NBR
Temperature range: -40 °C to 130 °C
Protection type: IP 65

Thread M16x1.5 to M63x1.5 for cables from Ø1.2mm to Ø18mm.
Sale
UNI-DICHT S4 - Stainless steel - 100103-47
Material: Stainless steel CrNiMo (DIN 1.4571)
Sealing insert: TPE-V
O-ring: NBR
Strain relief: acc. to EN 50262, version A
Temperature range: -40 °C to 135 °C
Protection type: IP 68

Thread M12x1.5 to M63x1.5 for cables from Ø4mm to Ø44mm.
Sale
UNI-DICHT - Brass - 100103-00
Material: brass, nickel-plated
Sealing insert: TPE
O-ring: NBR
Strain relief: acc. to EN 50262, version A
Temperature range: -40 °C to 130 °C
Protection type: IP 68

Thread M4x0.7 to M120x2 for cables from Ø0.9mm to Ø110mm.
Sale
Flexible hot air exhaust hose AEROCLIMA® Santo crush +150°C - 541-50-07
Light, very flexible and robust transport and suction hose for hight temperatures. Suitable for i.a. drying and combustion plants and garage exhaust systems for gas temperatures up to +150°C.
Crush resistant. Offers an excellent memory when crushed. It will spring back to shape when stepped.
Sale
Flexible hot air exhaust hose AEROCLIMA® Santo heavy +150°C - 541-50-05
Medium weight, very flexible transport and suction hose for high temperatures up to +150°C. Suitable for i.a. the extraction of steam and the transport of hot and cold air in the vehicle and machine manufacturing. Free of halogen and plasticizer.
Sale
Flexible hot air exhaust hose AEROCLIMA® Santo extra light +150°C - 541-50-01
Light, very flexible transport and suction hose for high temperatures up to +150°C. Suitable for i.a. the extraction of steam and the transport of hot and cold air in the vehicle and machine manufacturing. Free of halogen and plasticizer.
Sale
Flexible hot air exhaust hose AEROCLIMA® Santo light +150°C - 541-50-02
Light, very flexible transport and suction hose for high temperatures up to +150°C. Suitable for i.a. the extraction of steam and the transport of hot and cold air in the vehicle and machine manufacturing. Free of halogen and plasticizer.
Sale
PROGRESS-M Brass - Long, PG thread - 100101-20
Cable Glands
Material: brass, nickel-plated
Sealing insert: TPE
O-ring: NBR
Strain relief: acc. to EN 50262, version A
Temperature range: -40°C to 100°C
Protection type: IP 68/IP69K

Thread Pg 7 to Pg 48 for cables from Ø3.5mm to Ø49mm.
